KNN.pptx

K-nearest neighbors (KNN) is a non-parametric classification technique where an unlabeled sample is classified based on the labels of its k nearest neighbors in the training set, as determined by a distance function. The basic steps are to 1) compute the distance between the test sample and all training samples, 2) select the k nearest neighbors based on distance, and 3) assign the test sample the most common label of its k nearest neighbors. Key aspects include choosing an appropriate value of k, distance metrics, handling high-dimensional data, and reducing computational complexity through techniques like condensing.

Data & Analytics◦
Download to read offline
K Nearest Neighbor Classification
Bayes Classifier: Recap L P( HILSA | L) P( TUNA | L) P( SHARK | L) Maximum Aposteriori (MAP) Rule Distributions assumed to be of particular family (e.g., Gaussian), and parameters estimated from training data.
Bayes Classifier: Recap L +-  P( HILSA | L) P( TUNA | L) P( SHARK | L) Approximate Maximum Aposteriori (MAP) Rule Non-parametric (data driven) approach: consider a small window around L, Find which class is most populous in that window.
Nearest Neighbor Classifiers  Basic idea:  If it walks like a duck, quacks like a duck, then it’s probably a duck Training Records Test Record Compute Distance Choose k of the “nearest” records
Basic Idea  k-NN classification rule is to assign to a test sample the majority category label of its k nearest training samples  In practice, k is usually chosen to be odd, so as to avoid ties  The k = 1 rule is generally called the nearest- neighbor classification rule
Definition of Nearest Neighbor X X X (a) 1-nearest neighbor (b) 2-nearest neighbor (c) 3-nearest neighbor K-nearest neighbors of a record x are data points that have the k smallest distance to x
Voronoi Diagram Properties: 1) All possible points within a sample's Voronoi cell are the nearest neighboring points for that sample 2) For any sample, the nearest sample is determined by the closest Voronoi cell edge
Distance-weighted k-NN  Replace by: å = Î = k i i V v x f v q f 1 )) ( , ( max arg ) ( ˆ d ˆ f (q) = argmax vÎV 1 d xi,xq ( ) 2 d(v, f (xi)) i=1 k å General Kernel functions like Parzen Windows may be considered Instead of inverse distance.
Predicting Continuous Values  Replace by:  Note: unweighted corresponds to wi=1 for all i å å = = = k i i k i i i w x f w q f 1 1 ) ( ) ( ˆ å = Î = k i i i V v x f v w q f 1 )) ( , ( max arg ) ( ˆ d
Nearest-Neighbor Classifiers: Issues – The value of k, the number of nearest neighbors to retrieve – Choice of Distance Metric to compute distance between records – Computational complexity – Size of training set – Dimension of data
Value of K  Choosing the value of k:  If k is too small, sensitive to noise points  If k is too large, neighborhood may include points from other classes X Rule of thumb: K = sqrt(N) N: number of training points
Distance Metrics
Distance Measure: Scale Effects  Different features may have different measurement scales  E.g., patient weight in kg (range [50,200]) vs. blood protein values in ng/dL (range [-3,3])  Consequences  Patient weight will have a much greater influence on the distance between samples  May bias the performance of the classifier
Standardization  Transform raw feature values into z-scores   is the value for the ith sample and jth feature  is the average of all for feature j  is the standard deviation of all over all input samples  Range and scale of z-scores should be similar (providing distributions of raw feature values are alike) zij = xij - mj s j zij = xij - mj s j xij mj xij s j xij
Nearest Neighbor : Dimensionality  Problem with Euclidean measure:  High dimensional data  curse of dimensionality  Can produce counter-intuitive results  Shrinking density – sparsification effect 1 1 1 1 1 1 1 1 1 1 1 0 0 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 vs d = 1.4142 d = 1.4142
Distance for Nominal Attributes
Distance for Heterogeneous Data Wilson, D. R. and Martinez, T. R., Improved Heterogeneous Distance Functions, Journal of Artificial Intelligence Research, vol. 6, no. 1, pp. 1-34, 1997
Nearest Neighbour : Computational Complexity  Expensive  To determine the nearest neighbour of a query point q, must compute the distance to all N training examples + Pre-sort training examples into fast data structures (kd-trees) + Compute only an approximate distance (LSH) + Remove redundant data (condensing)  Storage Requirements  Must store all training data P + Remove redundant data (condensing) - Pre-sorting often increases the storage requirements  High Dimensional Data  “Curse of Dimensionality”  Required amount of training data increases exponentially with dimension  Computational cost also increases dramatically  Partitioning techniques degrade to linear search in high dimension
Reduction in Computational Complexity  Reduce size of training set  Condensation, editing  Use geometric data structure for high dimensional search
Condensation: Decision Regions Each cell contains one sample, and every location within the cell is closer to that sample than to any other sample. A Voronoi diagram divides the space into such cells. Every query point will be assigned the classification of the sample within that cell. The decision boundary separates the class regions based on the 1-NN decision rule. Knowledge of this boundary is sufficient to classify new points. The boundary itself is rarely computed; many algorithms seek to retain only those points necessary to generate an identical boundary.
Condensing  Aim is to reduce the number of training samples  Retain only the samples that are needed to define the decision boundary  Decision Boundary Consistent – a subset whose nearest neighbour decision boundary is identical to the boundary of the entire training set  Minimum Consistent Set – the smallest subset of the training data that correctly classifies all of the original training data Original data Condensed data Minimum Consistent Set
Condensing  Condensed Nearest Neighbour (CNN) 1. Initialize subset with a single (or K) training example 2. Classify all remaining samples using the subset, and transfer any incorrectly classified samples to the subset 3. Return to 2 until no transfers occurred or the subset is full •Incremental •Order dependent •Neither minimal nor decision boundary consistent •O(n3) for brute-force method
Condensing  Condensed Nearest Neighbour (CNN) 1. Initialize subset with a single training example 2. Classify all remaining samples using the subset, and transfer any incorrectly classified samples to the subset 3. Return to 2 until no transfers occurred or the subset is full
Condensing  Condensed Nearest Neighbour (CNN) 1. Initialize subset with a single training example 2. Classify all remaining samples using the subset, and transfer any incorrectly classified samples to the subset 3. Return to 2 until no transfers occurred or the subset is full
Condensing  Condensed Nearest Neighbour (CNN) 1. Initialize subset with a single training example 2. Classify all remaining samples using the subset, and transfer any incorrectly classified samples to the subset 3. Return to 2 until no transfers occurred or the subset is full
Condensing  Condensed Nearest Neighbour (CNN) 1. Initialize subset with a single training example 2. Classify all remaining samples using the subset, and transfer any incorrectly classified samples to the subset 3. Return to 2 until no transfers occurred or the subset is full
Condensing  Condensed Nearest Neighbour (CNN) 1. Initialize subset with a single training example 2. Classify all remaining samples using the subset, and transfer any incorrectly classified samples to the subset 3. Return to 2 until no transfers occurred or the subset is full
Condensing  Condensed Nearest Neighbour (CNN) 1. Initialize subset with a single training example 2. Classify all remaining samples using the subset, and transfer any incorrectly classified samples to the subset 3. Return to 2 until no transfers occurred or the subset is full
High dimensional search  Given a point set and a nearest neighbor query point  Find the points enclosed in a rectangle (range) around the query  Perform linear search for nearest neighbor only in the rectangle Query
kd-tree: data structure for range search  Index data into a tree  Search on the tree  Tree construction: At each level we use a different dimension to split x=5 y=3 y=6 x=6 A B C D E x<5 x>=5
kd-tree example X=5 y=5 y=6 x=3 y=2 x=8 x=7 X=5 X=8 X=7 X=3 Y=6 Y=2
KNN: Alternate Terminologies  Instance Based Learning  Lazy Learning  Case Based Reasoning  Exemplar Based Learning
